| Category | Item | Index |
|---|---|---|
| Optical System | Focal Length | 400mm |
| Wavelength range | 165~589nm (Extendable) | |
| Detector | High resolution CCD Multi detectors | |
| Degree of vacuum | Auto control within 6-20 pa | |
| Pixel resolution | 30pm | |
| Grating line | 2400m1/mm | |
| First order spectral line dispersion rare | 1.2nm/mm | |
| Average resolution ratio | 10pm/pixel | |
| Spectral Coverage | Full spectrum | |
| Temperature Control | Light room temperature is controlled automatically | |
| Spark Source | Type | Digital arc and spark source |
| Spark frequency | 100-1000HZ | |
| Discharge current | 1-400A | |
| Ignition voltage | >15000V | |
| Excitation light | Optimization of discharge parameters design | |
| High energy precombustion technology HEPS | ||
| Processor | High-speed data synchronization acquisition and processing | |
| Spark Stand | Electrode | Tungsten electrode technology |
| Make up | Thermal deformation self-compensation design | |
| Argon Consumption | Argon flushed with minimal consumption of Argon | |
| Discharge Technology | Spray discharge electrode technology | |
| Electrode Technology | Adjustable electrode technology | |
| Others | Measurable elements | Fe, Al, Cu, Ni, Ti, Co, Zn, Sn, Mg, Pb etc |
| Dimension | 800mm(L)*700mm*470mm(H) | |
| Weight | About 100kg | |
| Storage temperature | 0℃-45℃ | |
| Operating temperature | 10℃-35℃, 23±2℃ is recommended | |
| Power | AC220V/50Hz(Customized) | |
| Power consumption | Excitation:700W / Stand by:100W | |
| Argon quality | 99.999%, Argon pressure>4Mpa | |
| Argon consumption | 5L/min during spark mode | |
| Interface | Ethernet data transmission based on DM9000A |
